Note
• The at head M3x4 screws require a Phillips #2 screwdriver.
• A torque of 5 kgf.cm (4.34 lbf.in) ± 0.5 kgf.cm (0.43 lbf.in) is recommended for
electric screwdrivers.
15. Optional: Remove existing memory modules.
a. Push the retention clips outward simultaneously to release the module.
Warning
Attempting to remove a module that is not completely released may damage the
module and the system board.
b. Hold the module by the edges.
c. Carefully slide the module out of the slot.
16. Optional: Remove existing M.2 SSDs.
Note
Skip this step if your device does not have M.2 SSD slots.
a. Pull out the pushpin.
| NAS Repair Manual
Category E NAS Models 150
