QNAP TS 77 Series User Manual

No. Component No. Component
2 Enter button 7 USB One-Touch Copy button
3 Select button 8 USB 3.0 One-Touch Copy port
4 Infrared (IR) receiver 9 SSD LEDs
5 Drive LEDs 10 M.2 SSD LEDs
Rear Panel
No. Component No. Component
1 PCIe full-height cover 10 Kensington security slot
2 USB 3.0 ports 11 Reset button
3 USB 3.1 Gen 2 10Gbps Type-A port 12 USB 3.0 ports
4 Gigabit Ethernet (RJ45) port 2 13 USB 3.1 Gen 2 10Gbps Type-C port
5 Gigabit Ethernet (RJ45) port 1 14 3.5 mm line-out jack
6 Gigabit Ethernet (RJ45) port 3 15 3.5 mm dynamic microphone jacks
7 Gigabit Ethernet (RJ45) port 4 16 Console port
8 Power input 17 PCIe low-profile cover
9 Power switch 18 PCIe low-profile cover
