11
Chapter 1. CPU and Memory Specifications
Caution: Modifying the hardware, software, or firmware of the QNAP products will
void the warranty. QNAP is not responsible for any form of damage or loss of data caused
by modding the QNAP products. Users should bear their own risks of all sorts of possible
data loss or system instabilities due to changing the hardware parts, modifying the default
system firmware or installing any unauthorized third party applications on QNAP products.
System TS-112P TS-212P
CPU Marvell 1.6GHz Marvell 1.6GHz
Memory 512MB DDR2 512MB DDR2
Flash 16MB 16MB
Memory
replaceable
- -
Number of RAM
slots
- -
Number of hard
drive slots
1 2
System TS-128 TS-228
CPU
Dual-core ARM®v7
1.1GHz
Dual-core ARM®v7
1.1GHz
Memory
1GB DDR3
1GB DDR3
Flash
4GB
4GB
Memory
replaceable
-
-
Number of RAM
slots
- -
Number of hard
drive slots
1 (3.5” HDDs only) 2 (3.5” HDDs only)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the QNAP TS-831X and is the answer not in the manual?

QNAP TS-831X Specifications

General IconGeneral
RAID levels0, 1, 5, 6, 10, JBOD
RAID supportYes
Storage drive size- \
Storage drive capacity0 GB
Supported file systemsFAT32, HFS+, NTFS, ext3, ext4
Storage drive interface-
Storage drives installedNo
Storage drive sizes supported2.5, 3.5 \
Supported storage drive typesHDD & SSD
Total installed storage capacity0 TB
Number of storage drives installed0
Number of storage drives supported8
Supported storage drive interfacesSerial ATA, Serial ATA II, Serial ATA III
TypeNAS
Noise level20.6 dB
Device classHome & Home Office
Backup featuresCloud, USB drive, iSCSI LUN
Number of users4096 user(s)
Browser supportedMicrosoft Internet Explorer 10+, Mozilla Firefox 8+, Apple Safari 4+, Google Chrome
Security algorithms256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH
Operating system version4.2
Operating system installedQNAP Turbo System
Server operating systems supportedWindows Server 2003, Windows Server 2003 R2, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Processor cores4
Processor modelAlpine AL-314
Processor familyAnnapurna Labs
Processor frequency1.7 GHz
Processor architectureARM Cortex-A15
Fan voltage12 V
Output current3.5 A
AC input voltage110 - 240 V
AC input frequency50 - 60 Hz
Power supply locationBuilt-in
Power consumption (typical)46.36 W
Number of power supply units1
Power consumption (HDD standby)19.47 W
Power supply unit (PSU) capacity250 W
Cables includedAC, LAN (RJ-45)
Number of screws56
Flash memory512 MB
Memory slots2x SO-DIMM
Internal memory8 GB
Internal memory typeDDR3
Maximum RAM supported16 GB
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN data rate supported (max)10000 Mbit/s
Fiber optic connectorSFP+
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Chassis typeDesktop
Cooling typeActive
Display typeLCD
Fan diameter120 mm
Product colorBlack
LED indicatorsHDD, Power, Status, USB
Number of fans2 fan(s)
Cable lock slot typeKensington
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
Weight and Dimensions IconWeight and Dimensions
Depth235 mm
Width298.2 mm
Height185.2 mm
Weight7300 g
Package weight8250 g
