QNAP TS-832PX User Manual

Method Description Requirements
Cloud installation If the NAS is connected to the
internet, you can do the following:
• Scan the QR code on the
NAS.
• Specify the Cloud Key.
• Log into your myQNAPcloud
account.
• Use myQNAPcloud Link to
remotely access your NAS.
• Complete the steps in the
Smart Installation Guide
wizard.
• Computer or mobile device
• myQNAPcloud account
• Cloud Key
Installing QTS Using Qfinder Pro
Warning
Installing QTS deletes all data on the drives. Back up your data before proceeding.
1. Power on the NAS.
2. Connect the NAS to your local area network.
3. Run Qfinder Pro on a computer that is connected to the same local area network.
Note
To download Qfinder Pro, go to https://www.qnap.com/utilities.
4. Locate the NAS in the list and then double-click the name or IP address.
5. Perform any of the following actions.
• To check for the latest available version, click Start.
The wizard downloads the latest available version, and then the NAS restarts after the download
is complete. If a newer version is not available, the wizard automatically displays the Smart
Installation Guide.
• To install the out-of-the-box version, click Skip.
6. Click Start Smart Installation Guide.
7. Specify the following information.
• NAS name: Specify a name with 1 to 14 characters. The name supports letters (A to Z, a to z),
numbers (0 to 9), and hyphens (-), but cannot end with a hyphen.
• Password: Specify an administrator password with 1 to 64 characters. The password supports all
ASCII characters.
8. Click Next.
9. Specify the time zone, date, and time.
TS-832PX User Guide
Installation and Configuration 30

QNAP TS-832PX Specifications

General

Type	NAS
Noise level	19.6 dB
Device class	Small & Medium Business
Backup features	Cloud, USB drive, iSCSI LUN
Browser supported	Apple Safari 7+, Google Chrome, Microsoft Internet Explorer 10+, Mozilla Firefox
Remotely operated	Yes
Security algorithms	256-bit AES, FIPS 140-2, HTTPS, SNMP, SSH
Operating system version	4.4.2
Operating system installed	QNAP Turbo System
Mac operating systems supported	Mac OS X 10.0 Cheetah, Mac OS X 10.1 Puma, Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina
Linux operating systems supported	CentOS 7.0, Ubuntu 14.04
Other operating systems supported	IBM AIX 7.1, IBM AIX 7.2, Solaris 10
Server operating systems supported	Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Processor cores	4
Processor model	AL324
Processor frequency	1.7 GHz
Processor architecture	ARM Cortex-A57
Processor manufacturer	Annapurna Labs
Number of processors supported	1
Fan voltage	12 V
Output current	3.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power supply location	Built-in
Power consumption (sleep)	27.949 W
Power consumption (typical)	50.858 W
Power supply unit (PSU) capacity	250 W
RAID levels	0, 1, 5+S, 5, 6, 6+HS, 10+HS, 10, 50, 60, JBOD
Storage drive size	- \
Storage drive capacity	- GB
Supported file systems	FAT32, HFS+, ext3, ext4
Storage drive interface	Serial ATA III
Installed storage drive type	HDD
Storage drive sizes supported	2.5, 3.5 \
Supported storage drive types	HDD & SSD
Total installed storage capacity	80 TB
Number of storage drives installed	-
Number of storage drives supported	8
Supported storage drive interfaces	Serial ATA II, Serial ATA III
Ethernet LAN data rates	10, 100, 1000, 2500, 10000 Mbit/s
Ethernet LAN data rate supported (max)	10000 Mbit/s
Chassis type	Tower
Cooling type	Active
Fan diameter	120 mm
Product color	Aluminium, Black
Fan diameter 2	60 mm
LED indicators	HDD, LAN, Status, System, USB
Number of fans	3 fan(s)
Cable lock slot type	Kensington
Cables included	AC, LAN (RJ-45)
Number of screws	56
Flash memory	512 MB
Internal memory	4 GB
Memory clock speed	2400 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4
Maximum RAM supported	16 GB
Fiber ports quantity	2
Fiber optic connector	SFP+
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	280.8 mm
Width	329.3 mm
Height	188.2 mm
Weight	6380 g
Package weight	8610 g
