No. Component No. Component
1 Ethernet port 3 (10GbE SFP+) 6 Power supply unit 2
2 USB 3.2 Gen 2 Type-A port 7 Ethernet port 2 (GbE RJ45)
3 Ethernet port 1 (GbE RJ45) 8 USB 3.2 Gen 1 Type-A ports
4 PCIe low-profile cover 9 Ethernet port 4 (10GbE SFP+)
5 Power supply unit 1 10 Reset button
System Board
TS-977XU, TS-977XU-RP
No. Component No. Component
1 PCIe slot 1 (PCIe 3.0 x16) 4 Memory slot 2 (Channel A, DIMM 2)
2 Memory slot 4 (Channel B, DIMM 4) 5 Memory slot 1 (Channel A, DIMM 1)
3 Memory slot 3 (Channel B, DIMM 3) - -
TS-x77XU User Guide
Product Overview 9
