Warning
• Do not touch the internal components, particularly the metal connectors.
• Do not bend the module.
7. Install a new module.
a. Align the notch with the ridge in the slot.
b. Insert the module into the slot.
c. Verify that the metal connectors are completely inserted into the slot.
d. Carefully press down on the module until the retention clips lock the module into place.
8. Slide each drive tray back into the NAS.
TS-x62, TS-x64 User Guide
Installation and Conguration 36
