System Board
Note
This image does not show the chassis.
No. Component No. Component
1 PCIe 3.0 x 16 slot
Note
A Thunderbolt™ 3 expansion card
is preinstalled in this slot.
4 M.2 SSD slot 1
2 PCIe 3.0 x 4 slot 5 Memory slot 1
3 M.2 SSD slot 2 6 Memory slot 2
TVS-x72XT User Guide
Product Overview 12
