TVS-872XT
No. Component No. Component
1 LCD panel 7 USB One Touch Copy button
2 Enter button 8 IR sensor
3 Select button 9 M.2 SSD LEDs
4 Drive LEDs 10 USB LED
5 Power button 11 LAN LED
6 USB 3.1 Gen 2 One Touch Copy Type-A port 12 Status LED
Rear Panel
TVS-472XT
TVS-x72XT User Guide
Product Overview 9
