QNAP TVS-882BRT3 User Manual

Component TVS-882BRT3
PCIe slots • 1 x PCIe 3.0 x8
Note
QNAP dual-port Thunderbolt™ expansion cards are pre-installed
on the two PCIe 3.0 x4 slots.
Audiovisual
LCD Panel Monochrome LCD with Enter & Select buttons
HDMI outputs 3 x HDMI v1.4b ports (up to 3840 x 2160 @ 30 Hz resolution)
Audio • 2 x 6.3 mm microphone jacks
• 1 x 3.5 mm line-out jack
• 2 x built-in speakers
Interface
Buttons • Power
• USB One Touch Copy
• Reset
LED indicators • Status
• Drives 1 to 8
• M.2 SSDs 1-2
IR sensor QNAP RM-IR004 remote control (MCE compatible)
Dimensions
Dimensions (H x W
x D)
234.6 x 369.9 x 319.8 mm
9.23 x 14.56 x 12.59 in
Net weight • NAS: 11.55 kg (25.46 lbs)
• 5.25-inch optical drive: 0.63kg (1.39 lbs)
Form factor Tower
Other
Flash memory 512 MB DOM
Power supply unit ATX 100-240 V, 3-1.5 V Output 250 W
Fans • System: 3 x 80 mm
• CPU: 1 x 90 mm
Sound level Sound pressure (LpAm) (bystander position): 21.6 dB
(with 8 x Seagate ST2000VN000-1HJ164 hard drive installed)
Operating
temperature
0 to 40˚C (32 to 104˚F)
Relative humidity • Non-condensing relative humidity: 5 to 95%
• Wet-bulb temperature: 27˚C (80.6˚F)
Note
Model specifications are subject to change without prior notice. To see the latest
specifications, go to https://www.qnap.com.
TVS-882BRT3 User Guide
Product Overview 6

QNAP TVS-882BRT3 Specifications

General

Brand	QNAP
Model	TVS-882BRT3
Category	Server
Language	English
