QNAP TVS-882BRT3 - Back Panel

No. Component No. Component
4 Status LED 9 M.2 LEDs
5 Power button 10 Optical drive bay
Back Panel
No. Component No. Component
1 PCIe 3.0 x8 cover 6 Gigabit RJ45 Ethernet ports
2 Power port 7 3.5 mm speaker jack
3 Power switch 8 6.3 mm microphone jacks
4 Reset button 9 USB 3.0 ports
5 HDMI ports 10 Thunderbolt™ 3 ports
TVS-882BRT3 User Guide
Product Overview 8
