18
VII. Specifications (cont.)
POWER CONSUMPTION
(see chart on page 13)
Normal operation: 1/8 power @ 4Ω per channel
Worst case continuous program: 1/3 power @ 2Ω per channel
Maximum: full power @ 2Ω per channel
Multiply current times 0.5 for 220-240 VAC operation
Model Channel Load AC Current, Full Power AC Current, 1/3 Power AC Current, 1/8 Power AC Current, Idle
CX4, CX4T 8Ω + 8Ω 5.7 A 3.4 A 2.3 A 0.4 A
4Ω + 4Ω 9.2 A 5.2 A 3.5 A 0.4 A
2Ω + 2Ω 13.3 A 7.4 A 4.9 A 0.4 A
25V, 70V, 100V 8.7 A 5.0 A 3.3 A 0.4 A
CX6, CX6T 8Ω + 8Ω 7.7 A 4.9 A 3.3 A 0.6 A
4Ω + 4Ω 12.5 A 7.4 A 4.8 A 0.6 A
2Ω + 2Ω 18.8 A 11.0 A 7.2 A 0.6 A
25V, 70V, 100V 11.2 A 6.7 A 4.5 A 0.6 A
CX12, CX12T 8Ω + 8Ω 14.7 A 8.4 A 4.5 A 0.8 A
4Ω + 4Ω 23 A 12.4 A 6.1 A 0.8 A
2Ω + 2Ω 33 A 16.5 A 8.0 A 0.8 A
25V, 70V, 100V 21 A 10.9 A 5.7 A 0.8 A
DIMENSIONS
Faceplate Width Standard 19" (48.3 cm) Rack Mounting
Chassis Depth 17.9" (45.5 cm) deep (to rear support ears)
Faceplate Height CX4 & CX4T: 3.5" (13.3 cm)
CX6 & CX6T; CX12 & CX12T: 5.25" (13.3 cm)
WEIGHT CX4 CX4T CX6 CX6T CX12 CX12T
Shipping 33 lb; 16.4 kg 42 lb; 21 kg 49 lb; 24 kg 62 lb; 28 kg 58 lb; 26.3 kg 75 lb; 34 kg
Net 27 lb; 13.6 kg 37 lb; 18.2 kg 42 lb; 20 kg 55 lb; 25 kg 50 lb; 22.7 kg 67 lb; 30.4 kg
