TD-000520-00-A
Q-SYS I/O-8 Flex Channel Expander Specifications
Controls and Indicators
Front Panel Controls "NEXT" OLED page forward capacitive touch button
"ID" device identification capacitive touch button
"Clear Network Settings" invoked when "NEXT" and "ID" are pressed simultaneously
Front Panel Conenctors AUX USB: USB Host x 2 (Type A connectors)
Front Panel Indicators Blue "POWER" LED
304 x 96 monochrome OLED display
Rear Panel Connectors Audio Flex I/O: 12-pos blue Euro Block x 2
GPIO: 10-pos black Euro Block x 2 (GPI = 1 x 10, GPO = 1 x 10)
RS232: 3-pos black Euro Block
AUX USB Host: USB Host x 2 (Type A connectors)
AUX USB Device: USB Device (Type B connector)
Media Network LAN A/PoE+ Power In: RJ45 1000 Mbps
Media Network LAN B RJ45 1000 Mbps
AUX PWR In: 2-pos: green Euro Block
GPIO
General Purpose Inputs 0-24VDC analog input or contact closure, with configurable 5.11K pullup to +12V
General Purpose Outputs Open collector, 24VDC at 200mA max, internal 1.0K pullup to 3.3V
GPIO 12VDC Power Pins 12VDC out at 100mA max
Miscellaneous
PoE+ Power Input IEEE 802.3at class 4 compliant PD, requires full power from an IEEE 802.3at class 4
compliant PSE via LAN A port
External Power Input 24VDC, 1.2A supplied via external power input, may be used as the primary power source
or as a backup to the PoE+ source
Operating Temperature Range
0°C - 50°C
BTU/Hour 70 BTUs (power conversion estimate under typical load)
Cooling Convection
Humidity 5 - 85% RH, non-condensing
Vibration > 20 Grms
Regulatory FCC 47 CFR Part 15 Class A, IC ICES-003, CE (EN55032, EN55035), EU RoHS directive
2011/65/EU, WEEE directive 2012/19/EU, China RoHS directive GB/T26572, EAC, EFUP
10 YR, RCM
Estimated Product Life Cycle 20 years
Product Deminsions 8.66" x 9.43" x 1.75" (220mm x 240mm x 44mm), 1RU half rack
Shipping Carton Deminsions 20" x 12" x 4" (508mm x 305mm x 102mm)
Shipping Weight 6 lbs
Included Accessories Connector kit, rack ears, surface mount kit, safety instructions and regulatory statements
document warranty statement
Specifications subject to change without notice.
