6
TD-000520-00-A
Installation
Ventilation
• Recommend 1RU (1.75 in / 44.45 mm) space above I/O-8 Flex.
• Minimum open space of 6 inches measured from back of I/O-8 Flex.
NOTE: In order to provide adequate dissipation of
heat, keep the space directly above and to the rear of
the I/O-8 Flex free of obstacles.
Select the I/O-8 Flex Installation Configuration
Choose one of the following configuration options:
A. One I/O-8 Flex 19-inch Rack (Left or Right Mount) D. Under Table or on Wall
B. Two I/O-8 Flex 19-inch Rack (Front or Rear Facing Out) E. Free-Standing on Desk/Table
C. One I/O-8 Flex Half Rack (Front or Rear Facing Out)
