QSC Q-SYS User Manual

8
TD-000520-00-A
C. One I/O-8 Flex Half Rack ( Front or Rear Facing Out )
1. (1)
2. (2)
3. (6)
1
2
3
3
2
1
2
3
Top Side
Front Panel
Top Side
Rear Panel
D. Under Table or on Wall
1. (1)
2. (2)
3. (6)
4. (4) Not supplied – use appropriate screws
for mountingsurface.
5. Mounting Surface
1
2
3
4
5
Mounting Surface
Bottom Side
Front Panel
