RMX Series Technical Service Manual (2RU models) 21
TD-000098-00 rev. C
RE-002202-GP 4718-220J-2-P RMF 1W 22 5% AT FP 2 R236, R237
RE-082005-GP 471B-821J-1-X RMF 5W 820 OHM 5% AL METAL 2 R257, R258
RE-120007-GP 471B-202J-1-X RMF 5W 2K 5% AL METAL 2 R233, R235
RE-122006-GP 4756-2226-3-06 SVR 2.2K H3 7X7 2 R239, R240
RE-190903-GP 4717-9091-2 RMF 1/2W 9.09K 1% AT 1 R123
RE-210010-GP 4717-103A-2 RMF 1/2W 10.0K 1% AT 2 R122, R222
XF-000190-GP 1804-1030-0 SPRING COIL 2uH 1 L200
Channel 2 SMT parts
CA-056001-GP 150F-560K-J-BD CC 50V 56PF 10% 0805 2 C110, C210
CA-056002-GP 15CG-560J-6-CF CTC 0/30 56P 5% 1206 2 C111, C211
CA-118000-GP 150F-181K-J-BD CC 50V 180PF 5% 0805 4 C101, C103, C201, C203
CA-210011-GP 150H-102J-6-CF CC 100V 0.001µF 5% 1206 1 C214
CA-222007-GP 150F-222K-6-CF 50V .0022UF 10% 1206 1 C215
CA-410013-GP 150F-104K-6-CF CER 2 1206 10% 50V .1UF 3 C100, C102, C104
IC-000212-GP 3131-9730-0 IC NE5517D 1 U10
QD-000201-GP 4804-1480-3 DIODE LL4148 SM 15 D102, D103, D105, D106, D202–D206, D211–D216
QD-000204-GP 4860-0640-3 XISTOR NPN 60V 200MA 3904 SOT-23 2 Q201, Q202
QD-000205-GP 4853-9060-3 XISTOR PNP 40V 0.2A TR3906 SOT-23 2 Q100, Q200
RE-004702-GP 4720-470J-J RMG 1/10W 47 OHM 5% 0805 1 R224
RE-010006-GP 4720-101J-J RMG 1/10W 100 5% 6 R109, R110, R127, R209, R211, R227
RE-027003-GP 4720-271J-J RMG 1/10W 270 OHM 5% 6 R111, R113, R120, R210, R213, R220
RE-082003-GP 4721-821J-6 RMG 1/8W 820 OHM 5% 1206 4 R115, R215, R230, R232
RE-110012-GP 4720-102J-J RMG 1/10W 1K 5% 0805 3 R102, R126, R202
RE-115004-GP 4720-152J-J RMG 1/10W 1.5K 5% 0805 1 R229
RE-133007-GP 4720-332J-J RMG 1/10W 3.3K 5% 0805 1 R24
RE-147001-GP 4720-472J-J RMG 1/10W 4.7K 5% 0805 2 R114, R214
RE-175003-GP 4720-752J-J RMG 1/10W 7.5K 5% 0805 2 R108, R208
RE-210006-GP 4720-103J-J RMG 1/10W 10K 5% 0805 3 R103, R203, R228
RE-210007-GP 4720-103A-J 10K 1% 1/10W THK FLM 0805 8 R100, R101, R105, R106, R200, R201, R205, R206
RE-220005-GP 4720-203A-J RMG 1/10W 20K 1% 0805 4 R117, R121, R217, R221
RE-233001-GP 4721-333J-6 RMG 1/8W 33K 1% 1206 2 R22, R23
RE-239001-GP 4720-393J-J RMG 1/10W 39K 5% 0805 2 R107, R207
RE-247004-GP 4721-473J-6 RMG 1/8W 47K 5% 1206 1 R225
RE-315003-GP 4721-154J-6 RMG 1/8W 150K 5% 1206 2 R104, R204
RE-315004-GP 4721-154A-6 RMG 1/8W 150K 1% 1206 4 R118, R119, R218, R219
RE-339001-GP 4721-394J-6 RMG 1/8W 390K 5% 1206 2 R116, R216
Input Board Assembly
(was PCB-QZ010C-INP)
CA-147006-GP 150F-471J-5-OF 470PF 5% 50V CER NPO 4 C1–C4
CO-000204-GP 2113-1337-1 CONN XLR F VERT PLASTIC 2 J101, J201
CO-000234-GP 2113-1335-0 5 POLE INPUT TERMINAL BLOCK 1 J5
CO-000235-GP 2113-1652-0 PHONE JACK 06.4 2 J102, J202
SW-000089-GP 5200-4713-0 10 POLE DIP SWITCH 1 SW1
WC-000194-GP 7010-9860-0 RIBBON CABLE 26 PIN IEC 1 J1
Output Board Assembly
(was PCB-QZ010C-OUT)
CO-000236-GP 2113-1336-1 SPEAKON NEUTRIK 4 WIRE 2 J100, J200
PA-000043-00 2113-1338-0 PLATE ASSY,PLX/RMX,OUTPUT,, 1 J103
PL-000055-00 4154-2111-0 OUTPUT POST PLUG FOR CE (RED) 2 For European models only
PL-000056-00 4154-2121-0 OUTPUT POST PLUG FOR CE (BLACK) 2 For European models only
RMX850 Channel 2 module (continued)
QSC part # Old QSC part # Description Qty. Notes or Component Reference
