RMX Series Technical Service Manual (2RU models) 29
TD-000098-00 rev. C
6.4 RMX2450 Replacement Parts
QSC part # Old QSC part # Description Qty. Notes or Component Reference
Misc.
CO-000211-GP 2113-1144-0 IEC POWER INLET 1
CH-000194-GP 4134-9101-0 METAL WIND GUIDE 1
MS-000137-GP 4154-0361-0 FAN GUIDE 1
MS-000138-GP 8900-9050-1 DC FAN 24V 80X80 (+5V) 1
SW-000088-GP 5200-4717-0 ROCKER POWER SWITCH 1
SW-000091-GP 5200-3531-0 CIRCUIT BREAKER 15A 1 For 120V models
SW-000094-GP 5200-4731-0 CIRCUIT BREAKER 8A 1 For 230V models
WC-000181-GP 7010-9640-0 AC CORD SET 15A 1 For 120V models
WC-000213-GP 7009-8620-0 PWR CORD, 230V (EURO) 1 For 230V models
*XF-000115-GP 1806-2507-0 XFMR RMX 2450 1 Discontinued; replaced by XF-000318-GP and XF-000319-GP
XF-000318-GP 1806-3987+0000 TRANSFORMER, 240V, RMX2450 1 For 230V models
XF-000319-GP 1806-3986+0000 TRANSFORMER, 120V, RMX2450 1 For 120V models
AC Board Assembly
(was PCB-QZ030C-PSU)
CA-422005-GP 153R-224K-5-Y1 CM 250V .22UF 10% RL 4 C127, C128, C227, C228
CA-810006-GP 157Q-108M-5-X9E 1000UF 35V 20% ELECTROLYTIC 1 C6
153T-473K-5-WS CM 400V 0.047UF 10% RL 1 C10
IC-000213-GP 3130-9270-0 IC 4N29 1 U2
MS-000125-GP 5400-1831-1 HEATSINK FOR RECTIFIER 4 REF: BR100, BR101, BR200, BR201
MS-000126-GP 5400-0831-0 HEATSINK, BRIDGE RECTIFIER 1 REF: Q3
QD-000200-GP 4840-1760-0 DIODE RECT 1A 200V DB103 1 BR1
QD-000214-GP 4860-2620-5 TR TIP31C SAMSUNG 1 Q3
QD-000227-GP 4840-2150-0 BRIDGE RECT 400V 25A 4 BR100, BR101, BR200, BR201
RE-000005-GP 8910-0273-0 POLYSWITCH 1.1A 0.15 OHM 1.5W 1 R1
RE-000270-GP 8910-0275-0 NTC 30A 1 OHM 1 R21
RE-001201-GP 471B-120J-1-X 12 5% 5W METAL OXIDE FILM 2 R28, R29
RE-012004-GP 4719-121J-1-X RMF 2W 120 OHM 5% 1 R17
RE-120003-GP 4701-202J-C RCF 1/8W 2K 5% ATS 1 R13
RE-168002-GP 4701-682J-C RCF 1/8W 6.8K 5% ATS 2 R9, R14
RE-210006-GP 4720-103J-J RMG 1/10W 10K 5% 0805 4 R31–R34 (January 2002 and later)
4701-474J-C RCF 1/8W 470K 5% ATS 1 R12
WP-002454-00 Channel 1 Module Assembly (right)
(was PCB-QZ030C-PWR2)
CA-210012-GP 153H-102J-5-IQ CM 100V .001UF 5% RL 5X 2 C131, C231
CA-215004-GP 153R-152J-5-XQ CM 250V 0.0015UF 5% RL 1 C114
CA-233004-GP 153F-332J-5-KW CM 50V .0033UF 5% RL 2 C172, C179
CA-322006-GP 153F-223J-5-LQ CM 50V .022UF 5% RL 2 C116, C119
CA-368004-GP 153R-683J-5-WWM 0.068UF 5% 250V FILM DIPPED 2 C124, C126
CA-410018-GP 153R-104J-5-YRM CM 250V .1UF 5% RL 2 C174, C175
CA-415004-GP 153F-154J-5-NLM 0.15U,5%,50V,CM,,RBT,7.5X 4 C108, C109, C208, C209
CA-422006-GP 153F-224J-5-NLM CM 50V 0.22UF 5% RL 2 C107, C207
CA-610009-GP 157Q-106M-5-IU CE 35V 10UF 20% RL 5 X 11 1 C171
CA-622007-GP 157E-226M-5-IUN CE 25V 22uF 20% RL 5X11 1 C129
CA-647006-GP 157D-476M-5-LUN CE 16NP 47UF 20% RL 2 C106, C206
CA-710009-GP 157E-107M-5-KW CE 25V 100UF 20% RL 4 C105, C173, C180, C205
CA-710010-GP 157D-107M-5-OUN CE 16NP 100UF 20% RL 8X11 2 C125, C225
CA-722006-GP 157E-227M-5-PU CE 25V 220UF 20% RL 4 C112, C113, C212, C213
CA-912001-GP 8910-0494-0 12000UF,20 PCNT,63V,CE,RL,, 4 C120–C123
CO-000217-GP 2102-130S-003 CONN 13 PIN STRAIGHT WAFER 1 J104
CO-000222-GP 2101-1991-0 8-PIN IC SOCKET 2 REF: U101, U201
CO-000223-GP 2101-2081-0 26-PIN DUAL ROW IEC 1 J103
HW-000020-GP 4134-8851-0 FUSE HOLDER 6.3MM 2 F100
IC-000211-GP 3130-2430-0 IC NE5532 OP AMP 2 U101, U201
MS-000127-GP 5120-0501-0 FUSE T20A/125V 6.4X32MM 1 F100
PT-110002-GP 4756-1016-3-06 TRIM POT,100,20 PCNT,0.15W,, 1 R131
*PT-225000-GP *4751-0110-0 RES VAR 2.5K RT ANGLE PCB 2 R112, R212 (May 2002 and later)
*PT-310006-GP *4750-6200-0 VR V012CPH, D-SHAFT 10K 2 R112, R212 (April 2002 and earlier)
QD-000197-GP 3700-4529-R LED 4.7MM RED W/STAND 2 LD100, LD200
QD-000199-GP 3700-4530-Y LED 4.7MM W/STAND YELLOW 2 LD101, LD201
