RMX Series Technical Service Manual (2RU models) 19
TD-000098-00 rev. C
6. Replacement parts
6.1 RMX850 Replacement Parts
QSC part # Old QSC part # Description Qty. Notes or Component Reference
Misc.
CH-000198-GP 4134-8432-0 RACK-MOUNT BRACKET 2
CO-000211-GP 2113-1144-0 AC INLET, 250V 15A 1
MS-000138-GP 8900-9050-1 DC FAN 24V 80X80 (+5V) 1
PL-000147-GP 2444-1001-1 KNOB RMX PLASTIC BLACK 2
SW-000086-GP 5200-3532-0 CIRCUIT BREAKER 10A 1 For 120V models
SW-000088-GP 5200-4717-0 ROCKER POWER SWITCH 1
SW-000093-GP 5200-4730-0 CIRCUIT BREAKER 5A 1 For 230V models
WC-000181-GP 7010-9640-0 AC CORD 15A, 14 AWG, ISA 1 For 120V models
WC-000213-GP 7009-8620-0 AC CORD SET CE 1 For 230V models
*XF-000117-GP 1806-2505-0 POWER TRANSFORMER RMX850 120V/230V 1 Discontinued; replaced by XF-000314-GP and XF-000315-GP
XF-000314-GP 1806-3983+0000 TRANSFORMER, 230V,RMX850 1 For 230V models
XF-000315-GP 1806-3982+0000 TRANSFORMER, 120V,RMX850 1 For 120V models
WP-008502-00 AC Board Assembly
(was PCB-QZ010C-PSU)
CA-422005-GP 153R-224K-5-Y1 CM 250V 0.22uF 10% RL 2 C127, C227
CA-810006-GP 157Q-108M-5-X9E 1000UF 35V 20% ELECTROLYTIC 1 C6
HW-000020-GP 4134-8851-0 FUSE HOLDER 6.3MM 4 REF: F100, F200
IC-000213-GP 3130-9270-0 IC 4N29 1 U2
MS-000126-GP 5400-0831-0 HEATSINK, BRIDGE RECTIFIER 1 REF: Q3
MS-000129-GP 5100-1030-3A FUSE T10A 125V/250V 2 F100, F200
QD-000200-GP 4840-1760-0 DIODE RECT 1A 200V DB103 1 BR1
QD-000214-GP 4860-2620-5 TR TIP31C SAMSUNG 1 Q3
QD-000227-GP 4840-2150-0 BRIDGE RECTIFIER 400V 25A 2 BR100, BR200
RE-000005-GP 8910-0273-0 POLYSWITCH 1.1A 0.15 OHM 1.5W 1 R1
RE-000270-GP 8910-0275-0 THERMAL NTC 30A 1 OHM 1 R21
RE-012004-GP 4719-121J-1-X RMF 2W 120 OHM 5% 1 R17
RE-120003-GP 4701-202J-C RCF 1/8W 2K 5% ATS 1 R13
RE-168002-GP 4701-682J-C RCF 1/8W 6.8K 5% ATS 2 R9, R14
4701-474J-C RCF 1/8W 470K 5% ATS 1 R12
WP-008503-00 Channel 1 Module Assembly (left)
(was PCB-QZ010C-PWR1)
CA-233004-GP 153F-332J-5-KW CM 50V .0033UF 5% RL 2 C117, C118
CA-322006-GP 153F-223J-5-LQ CM 50V 0.022UF 5% RL 2 C116, C119
CA-368004-GP 153R-683J-5-WWM 0.068UF 5% 250V FILM DIPPED 1 C124
CA-547008-GP 157R-475M-5-OV 4.7UF 20% 250V ELECTRO RAD 1 C7
CA-647005-GP 157F-476M-5-LU CE 50V 47UF 20% RL 1 C8
CA-847001-GP 8910-0062-0 CE 80V 4700U 20% RL 25X 2 C120, C121
PT-110002-GP 4756-1016-3-06 TRIM POT,100,20 PCNT,0.15W,, 1 R131
QD-000198-GP 3700-4531-G LED 4.7MM GRN W/STAND 1 LD1
QD-000202-GP 4804-0040-1 DIODE IN4004 AL 5 D1, D11, D12, D117, D118
QD-000203-GP 4838-15V6-2 DIOD ZNR 15V 1W SILICON EPIT 2 D8, D15
QD-000206-GP 4804-9340-2 DIOD RECT FAST, IN4934 AT 2 D108, D109
QD-000207-GP 4860-5020-5 XISTOR NPN 250V 0.5A MJE15032 1 Q105
QD-000208-GP 4860-5060-5 TR 2SA1943 T0-3P (L) 3 Q103, Q107, Q109
QD-000209-GP 4860-5050-5 TR 2SC5200 T0-3P (L) 3 Q108, Q110, Q112
QD-000210-GP 4860-5030-5 XISTOR PNP 250V MJE15033 1 Q106
QD-000211-GP 4860-8890-0 TR MPSA06 VCE 80V NS 1 Q5
*QD-000212-GP 4837-5B10-2 DIODE ZENER 1/2W 5.5-5.8V 2 D107, D110 (December 2003 and earlier)
*QD-000269-GP * DIODE ZENER 5.1V 5% .25W DO-35 2 D107, D110 (January 2004 and later)
RE-.02201-GP 471A-022K-5-N 0.22 OHM 5% 3W THK FLM 6 R142, R148, R149, R152, R153, R159
RE-.56006-GP 4719-5R6J-1-X RMF 2W 5.6 OHM 5% 1 R160
RE-.68001-GP 4718-6R8J-1-X RMF 1W 6.8 OHM 5% 2 R146, R147
RE-000250-GP 8910-0488-0 NTC RES 50 OHM 1 R134
