RMX Series Technical Service Manual (2RU models) 31
TD-000098-00 rev. C
RE-122007-GP 4720-222J-J RMG 1/10W 2.2K 5% 0805 1 R191
RE-130103-GP 4720-3011-J RMG 1/10W 3.01K 1% 0805 2 R24, R175
RE-147001-GP 4720-472J-J RMG 1/10W 4.7K 5% 0805 8 R114, R138, R174, R179, R187, R193, R214, R238
RE-159003-GP 4720-592A-J 5.9K 1% 1/10W THK FLM 0805 2 R171, R184
RE-175003-GP 4720-752J-J RMG 1/10W 7.5K 5% 0805 2 R108, R208
RE-210007-GP 4720-103A-J 10K 1% 1/10W THK FLM 0805 8 R100, R101, R105, R106, R200, R201, R205, R206
RE-210006-GP 4720-103J-J RMG 1/10W 10K 5% 0805 3 R103, R128, R203
RE-212001-GP 4720-123J-J RMG 1/10W 12K 5% 0805 1 R176
RE-224001-GP 4720-243J-J 24.0K 1% 1/10W THK FLM 0805 4 R117, R121, R217, R221
RE-239001-GP 4720-393J-J RMG 1/10W 39K 5% 0805 2 R107, R207
RE-247004-GP 4721-473J-6 RMG 1/8W 47K 5% 1206 1 R125
RE-247005-GP 4720-473J-J RMG 1/10W 47K 5% 0805 1 R183
RE-268003-GP 4721-683A-6 RMG 1/8W 68K 1% 1206 4 R22A, R22B, R23A, R23B
RE-315003-GP 4721-154J-6 RMG 1/8W 150K 5% 1206 6 R104, R173, R178, R186, R192, R204
RE-346401-GP 4721-4643-6 464K 1% 1/8W THK FLM 1206 3 R166, R167, R266
RE-347003-GP 4720-474J-J RMG 1/10W 470K 5% 0805 2 R172, R185
4721-101J-6 RMG 1/8W 100R 5% 1206 1 R197
4721-824J-6 RMG 1/8W 820K 5% 1206 2 R116, R216
WP-002453-00 Channel 2 Module Assembly (left)
(was PCB-QZ030C-PWR1)
CA-215004-GP 153R-152J-5-XQ CM 250V 0.0015UF 5% RL 1 C214
CA-233004-GP 153F-332J-5-KW CM 50V 3300pF 5% RL 6x12 2 C272, C279
CA-322006-GP 153F-223J-5-LQ CM 50V .022UF 5% RL 5% RL 2 C216, C219
CA-368004-GP 153R-683J-5-WWM 0.068UF 5% 250V FILM DIPPED 2 C224, C226
CA-410018-GP 153R-104J-5-YRM CM 250V 0.1u 5% RL 2 C274, C275
CA-547008-GP 157R-475M-5-OV 4.7UF 20% 250V ELECTRO RAD 1 C7
CA-610009-GP 157Q-106M-5-IU CE 35V 10UF 20% RL 5 X 11 1 C271
CA-622007-GP 157E-226M-5-IUN CE 25NP 22UF 20% RL 5X11 1 C229
CA-647005-GP 157F-476M-5-LU CE 50V 47UF 20% RL 1 C8
CA-710009-GP 157E-107M-5-KW CE 25V 100UF 20% RL 2 C273, C280
CA-912001-GP 8910-0494-0 12000UF,20 PCNT,63V,CE,RL,, 4 C220–C223
CO-000214-GP 2102-031S-004 CONN 3 PIN STRAIGHT WAFER 1 J257
CO-000217-GP 2102-130S-003 CONN 13 PIN STRAIGHT WAFER 1 J204
QD-000198-GP 3700-4531-G LED 4.7MM GRN W/STAND 1 LD1
HW-000020-GP 4134-8851-0 FUSE HOLDER 6.3MM 2 REF: F200
MS-000127-GP 5120-0501-0 FUSE T20A/125V 6.4X32MM 1 F200
PT-110002-GP 4756-1016-3-06 TRIM POT,100,20 PCNT,0.15W,, 1 R231
RE-.02201-GP 471A-022K-5-N 0.22 OHM 5% 3W THK FLM 8 R242, R243, R248, R249, R252, R253, R256, R259
RE-.15003-GP 4719-1R5J-1-X 1.5 OHM 5% 2W THK FLM 2 R281, R282
RE-.33001-GP 4718-3R3J-1-X RMF 1W 3.3 OHM 5% 2 R246, R247
RE-.56006-GP 4719-5R6J-1-X RMF 2W 5.6 OHM 5% 1 R260
RE-000250-GP 8910-0488-0 NTC RES 50 OHM 1 R234
RE-000260-GP 8910-0274-0 THERMAL PTC 60C 100 OHM 1 R7
RE-001005-GP 4715-100J-2 RMF 1/4W 10 OHM 5% 1 R263
RE-001201-GP 471B-120J-1-X 12 5% 5W METAL OXIDE FILM 4 R254, R255, R261, R262
RE-002202-GP 4718-220J-2-P RMF 1W 22 5% AT FP 2 R236, R237
RE-010008-GP 4715-101J-2 RMF 1/4W 100 OHM 5% 1 R264
RE-122006-GP 4756-2226-3-06 SVR 2.2K H3 7X7 2 R239, R240
RE-122008-GP 471B-222J-1-X RMF 5W 2.2K 5% METAL 3 R257, R258, R298
RE-151003-GP 471B-512J-1-X RMF 5W 5.1K 5% AL METAL 2 R280, R288
RE-182002-GP 471B-822J-1-X RMF 5W 8.2K 5% AL METAL 4 R218, R219, R233, R235
RE-212002-GP 4718-123J-2-X RMF 1W 12K 5% AT METAL 2 R277, R294
RE-215007-GP 4718-153J-2-X RMF 1W 15K 5% METAL 1 R265
RE-233002-GP 4719-333J-2-X RMF 2W 33K 5% METAL 2 R2, R5
QD-000202-GP 4804-0040-1 DIODE IN4004 AL 5 D1, D11, D13, D217, D218
QD-000203-GP 4838-15V6-2 DIOD ZNR 15V 1W SILICON EPIT 2 D8, D15
QD-000206-GP 4804-9340-2 DIOD RECT FAST, IN4934 AT D208, D209
QD-000207-GP 4860-5020-5 XISTOR NPN 250V 0.5A MJE15032 1 Q205
QD-000208-GP 4860-5060-5 TR 2SA1943 T0-3P (L) 3 Q203, Q207, Q209, Q211
QD-000209-GP 4860-5050-5 TR 2SC5200 T0-3P (L) 3 Q204, Q208, Q210, Q212
QD-000210-GP 4860-5030-5 XISTOR PNP 250V MJE15033 1 Q206
RMX2450 Channel 1 module (continued)
QSC part # Revised QSC # Description Qty. Notes or Component Reference
To Next Page
