QTech XLINE Series

QIR100H| © 2022 Inim Electronics S.r.l.
11
2.3 Balancing
6K8Ω
3K9Ω
Tx
2.3.5 Double zone balancing with EOL
DoublezoneswithEOLresistorscandiscriminate6conditionsontheentireterminal:
l
stand-byonbothzones
l
alarmonzone1andstandbyonzone2
l
alarmonzone2andstand-byonzone1
l
alarmonbothzones
l
tamper(wirecutting)
l
tamper(short-circuit)
6K8Ω
3K9Ω
3K9Ω
Tx
