QIR100H| © 2022 Inim Electronics S.r.l.
3
1.1 Functioning of the QIR100H detector
1. Qtech detectors
TheQtechseriesofdetectorstobeappliedinindoorinstallations.
Bymeansoftheamplification,filteringanddigitalanalysisofthesignalsdetectedbytheirsensors,these
devicesarecapableofdetectingmotionintheareatheywatchoverwithappropriatelyprogrammablesens-
itivity,immunitytofalsealarmsandadequateprotectionagainsttamper.
TheQtechdetectorseriesalsoprovides‘petimmune’versionsdedicatedtoapplicationsthatmustnotgen-
eratealarmsinthepresenceofanimalsofupto25kg.
1.1 Functioning of the QIR100H detector
Whenpowerissupplied,theredLEDblinks3timesthentheyellowLEDlightsupandthedetectorgoesinto
theself-calibrationphase.Within60secondsthedetectorentersoperationalstatusandtheyellowLED
turnsoff.Duringthe60secondself-calibrationphase,thepartitionmonitoredbythedetectormustbein
stand-bystatus,freefromobstaclesandpeoplemovingabout.
Thealarmoutput(‘ALARM’terminal)activatesandtheredLEDlightsupwhenthedetectorsensesthe
movementofabodywhosetemperatureisdifferentfromtheambienttemperature.
Thetamperoutput(‘TAMPER’terminals)activateswhenthelidisopened.
Ambienttemperaturecanaffectinfraredsensingcapability.Theinstallercanadjustthesensitivityofthe
detectorsthroughprogramming.
Changingthesensitivityofthesensorsdoesnotalwaysreducetherange,butitdoesreducetheabilityto
detectsmallchangesinheat/temperature.
Tamper protection
Thedetectorisprotectedagainstsabotageduetoopeningthelid.
1.2 Main features
l
Digitalsignalanalysis
l
Coverage15m
l
Detectionangle90°
l
Pulsecounter
l
Temperaturecompensation
l
SignallingLED
l
SignalsfrombypassableLEDs
l
Anti-openingprotection
l
Adjustablesensorsensitivity
