1.4 Technical specifications

1.3.1 Terminal board



+12V 1 Positivepowersupply

-12V 2 Negativepowersupply

ALARM 3-4 Alarmsignal(N.C.duringstand-by)

TAMPER 5-6 Tampersignaloutputterminals(N.C.duringstand-by)

1.3.2 LED signallings

RedLED Alarmsignal

YellowLED Initialization

1.4 Technical specifications

Power supply voltage

Input voltage

range:from10to16V

nominal:12.6V

Stand-by current draw 11mA@12.6V

Maximum current draw 13mA@12.6V

Detectors type digitaldualPIR

Detection mode Infraredemission

Alarm pulses from1to2

Intrusion alarm output N.C.,16V

,100mAmax

Tamper output N.C.,16V

,100mAmax

Signal minimum duration 1o3seconds

Detection range (max) 15m

Detection angle 90°

Security grade 2

Environmental class II

Installation method wall-mounting

Installation height 2.2m

Dimensions (HxWxD) 96x60x44mm

Weight 62g

Environmental operating conditions

Temperature from-10to+40°C

Relative humidity ≤93%withoutcondensation
