3. Programming
3. Programming
TheoperatingparametersofthedetectorsandtheadjustmentsofthesensitivityoftheQtechsensorscan
beprogrammedbymeansofthebuttonsandLEDsavailableonthePCB,throughtheirownprogramming
menu.
3.1 Programming from QIR100H
Tochangetheprogrammingofparameters,theQIR100Hdetectorhasaprogrammingmenuindicatedby
theblinkingonitscorrespondingLEDs.Withinthismenu,youcannavigateusingthe‘P1’and‘P2’buttons.
TheP1buttonallowsyoutoenterandexittheprogrammingmenuandtoscrollthroughthemenuoptions.
TheP2buttoncanbeusedtochangetheparametersrelatingtotheselectedoption.
The4LEDsindicate:
l
selectionoftheparameter,whentheyareONsolid
l
thevalueoftheparameter,whentheyareflashing
1.
Removethecover.
2.
Powerupthedetector.
3.
PressandholdtheP1buttonfor5secondsuntilalltheLEDsstartblinking.Whenthebuttonis
released,themenuwillhavethefirstoptionactive.
4.
UsetheP1buttontomovetothedifferentoptionsonthemenu(
see).TheLEDcombination(the
LEDswhichblink)identifiestheoptionconcerned.
5.
BypressingtheP2buttonitispossibletoviewthecurrentsettingoftheparameterandwithsub-
sequentpressestheparametercanbechangeduntilthedesiredsettingisobtained.
6.
ItispossibletochangethemenuoptionbypressingtheP1buttonagainuntilthedesiredparameter
isreached.
7.
Toexitprogrammingwithoutsavingchanges,wait30secondswithoutpressinganybuttonordis-
connectthepowersupply.
Toexitprogrammingandconfirmallchanges,pressandholdtheP1buttonfor5seconds,untilthe
LEDsblinkquickly.
8.
Closethecasingandcompletetheinstallationprocedure.
Default
ResetofprogrammingisachievedwiththedevicepoweredupandbyholdingdownbuttonsP1andP2sim-
ultaneouslyfor10seconds.
Thisleadstothesequentiallighting(oneevery2seconds)ofall4LEDs.WhenalltheLEDsareon,thebut-
tonscanbereleasedandinthiswayresetallprogrammingmenustofactorydatasettings.
