Chapter 2 Installation
Warning: Before you install the Hard Disks, please make sure the
power of DVR is switched off.
2.1 HDD Installation
Installation notice
The DVR by factory default has not HDD installed. Based on the record
schedule, you can calculate the total capacity you need (refer to Appendix
A).
HDD installation
1. Open the DVR box.
2. If you want to install 2 HDD for one IDE interface, please set master
and slave HDD (set the jumpers properly in the HD). If you want to
install 4 HDD, please remove CD-R/W mount bracket.
3. Place the HDD on the soleplate and fix it with screw.
4. Connect the ATA data cable correctly. The cable has three
connectors for DVR main board, master HDD and slaver HDD.
5. Plug the HDD power connector.
6. Cover and fix the DVR box.
Note: After you install the HDD, you must format them. Please refer to
section 6.4.
