Quadra-Fire PELLET INSERT CB1200I - Component Locations

Page 42
7014-188B
February 3, 2010
R
CB1200-I Pellet Insert
R
R
Terminal Block
Center 2 Screws for
Thermostat Wires
Power Outlet
Heat Output
Switch
Reset Button
Red Call Light
Fuse
Control Box
Blue
Blinking
Light
Red/ Green
Light
B. Component Locations
Figure 42.1
Exhaust
Blower
Convection
Blower
Exhaust
Transition
Assembly
Figure 42.2
