Quadra-Fire SANTAFE-C - Table of Contents

3April 2, 2019 7050-802B
SANTA FE FREESTANDING
Quadra-Fire is a registered trademark of Hearth & Home Technologies.
A. Sample of Serial Number / Safety Label ......... 2
B. Warranty Policy ............................ 4
1 Listing and Code Approvals ..............7
A. Appliance Certication....................... 7
B. BTU & E󰀩ciency Specications ............... 7
C. Glass Specications ........................ 8
D. Electrical Rating ........................... 8
E. Mobile Home Approved ...................... 8
F. Sleeping Room ............................ 8
G. California - Prop65 ......................... 8
2 Operating Instructions .......................9
A. Fire Safety ................................ 9
B. Non-Combustible Materials ................... 9
C. Combustible Materials....................... 9
D. Fuel Material and Fuel Storage................ 9
E. Before Your First Fire ...................... 10
F. Filling the Hopper.......................... 10
G. General Operating Information ............... 11
H. Starting Your First Fire ..................... 11
I. Fire Characteristics......................... 12
J. Feed Rate Adjustment Instructions ............ 12
K. Ignition Cycles ............................ 13
L. Restarting the Appliance .................... 13
M. Clear Space ............................. 13
N. Thermostat Controls ....................... 14
O. Thermostat Setup Options .................. 14
P. Thermostat Operation Instructions............. 15
Q. Thermostat Temperature Programs ........... 15
R. Thermostat Other Features.................. 16
S. Thermostat Battery Replacement ............. 17
T. Frequently Asked Questions ................. 18
3 Maintenance and Service .................19
A. Proper Shutdown Procedure ................. 19
B. Quick Reference Maintenance Chart .......... 19
C. General Maintenance and Cleaning ........... 20
D. Soot or Creosote Fire Awareness ............. 23
E. High Ash Fuel Content Maintenance........... 23
4 Troubleshooting Guide .....................24
5 Service Parts Replacement ..............26
A. Blower Replacement ....................... 26
B. Snap Disc #2 Replacement.................. 27
C. Ba󰀪e Replacement........................ 28
D. Brick Replacement ........................ 28
E. Igniter Replacement ....................... 29
F. Glass Replacement ........................ 29
6 Reference Materials ..........................30
A. Component Functions ..................... 30
B. Component Locations ...................... 32
C. Service & Maintenance Log ................. 33
D. Exploded Drawings ........................ 34
E. Service Parts ............................. 35
F. Accessories .............................. 38
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
