810-1902-03 Rev D TM1 Installation Guide
15
Relays
There are five dry-contact relays which can be wired for normally-open (NO) or normally-closed (NC)
configuration. The relays are defined as follows:
PRGM-0 H2 ppm alarm
PRGM-1 H2 ROC alarm
PRGM-2 Moisture ppm alarm
SVC Service Events
PWR Loss of Power
NOTE: The relay contact ratings for resistive loads are:
Max switched Power 100W or 600VA
Max switched Current 3A
Max switched Voltage 150VDC or 300VAC
