QUANTA STRATOS S210 Series S210-X12RS User Manual

ABOUT THE SERVER 3.5” HDD SYSTEM
1-6
3.5” HDD System
Figure 1-2. 3.5” HDD System Component Description
1
2
4
5
6
7
3
Table 1-3: 3.5” HDD System Component Description
N
O.ITEM DESCRIPTION
1.
Riser Assembly
(1) PCIe x16 G3 low profile riser slot
(1) PCIe x8 G3 10GbE SFP+ Mezzanine slot
(1) PCIe x8 G3 Quanta LSISAS/RAID Mezzanine
slot
2. Hot-Swap PSU (2) Power supply units
3. Front Panel Control and LED panel for system status
4. iBBU holder Backup battery unit for mezzanine expansion card
5. 3.5 Hard Drives (4) 3.5” hard disk drives (HDD)
6. System Fan (6) Fan module assembly
7. Air Duct Maintains proper airflow throughout system
