QUANTA STRATOS S210 Series S210-X12RS - 3.5 HDD System Front Features

ABOUT THE SERVER 3.5” HDD SYSTEM
1-7
3.5” HDD System Front Features
Figure 1-3. 3.5” HDD System Front Features
3.5” HDD System Front Panel Definition 3.5” HDD System Front Control Panel
1
2
Table 1-4: 3.5” HDD Front Panel Definition
I
TEM NAME DESCRIPTION
1 Control Panel Connect USB devices to these ports
2 HDD Bays Insert HDDs here.
Table 1-5: 3.5” HDD System LED Function and Behavior
I
TEM ICON NAME DESCRIPTION
1
Front USB
ports
Connect USB devices to these ports
123 456 7 8
