Quantech QTC2015T - Design Parameters

FORM QTC2-eg1 (515)
QUANTECH
13
NOTES:
1. Forleavingbrinetemperaturebelow40°F(4.4°C), contactyournearestQuantechSalesOfcefor ap-
plication requirements.
2. Forleavingwatertemperaturehigherthan55°F(12.8°C),contactthenearestQuantechSalesOfcefor
application guidelines.
3. The evaporator is protected against freezing to -20°F (-28.8°C) with an electric heater as standard.
4. For operation at temperatures below 25°F (-3.9°C), the optional Low Ambient Kit will need to be installed
on the system (for QTC2040T-045T models only).
5. For operation at temperatures above 115°F (46.1°C), the optional High Ambient Kit will need to be in-
stalled on the system.
Design Parameters
QTC2 ENGLISH
MODEL
LEAVING WATER
TEMPERATURE (°F)
COOLER
FLOW (GPM)
AIR ON
CONDENSER (°F)
MIN MAX MIN MAX MIN MAX
015T 40 55 10 150 0 125
020T 40 55 10 150 0 125
025T 40 55 10 150 0 125
030T 40 55 10 150 0 125
035T 40 55 40 200 0 125
040T 40 55 40 200 0 125
045T 40 55 60 300 0 125
QTC2 SI UNITS
MODEL
LEAVING WATER
TEMPERATURE (°C)
COOLER
FLOW (L/S)
AIR ON
CONDENSER (°C)
MIN MAX MIN MAX MIN MAX
015T 4.4 12.8 0.6 9.5 -17.7 51.7
020T 4.4 12.8 0.6 9.5 -17.7 51.7
025T 4.4 12.8 0.6 9.5 -17.7 51.7
030T 4.4 12.8 0.6 9.5 -17.7 51.7
035T 4.4 12.8 2.5 12.6 -17.7 51.7
040T 4.4 12.8 2.5 12.6 -17.7 51.7
045T 4.4 12.8 3.8 18.9 -17.7 51.7
