Quantech QTC2015T User Manual

QUANTECH
FORM QTC2-eg1 (515)
16
Physical Data and Nominal Ratings
ENGLISH
QTC2 015T 020T 025T 030T 035T 040T 045T
LENGTH 109.8 109.8 118.6 118.6 144.8 144.8 148.8
WIDTH 44.7 44.7 44.7 44.7 90.6 90.6 90.6
HEIGHT 46.1 46.1 50 50 47.8 47.8 62.6
NOMINAL TONS 14.5 17.8 24.3 28 34.9 38 45.2
EER (AT AHRI) 10.0 10.0 10.1 10.5 10.1 10.2 10.2
IPLV 14.6 15.5 13.4 14.5 14.4 14.7 15.0
Number of Refrigerant Circuits 1 1 1 1 2 2 2
Refrigerant Charge, Opt, R-410A (lbs) Circuit 1/Circuit 2 25 30 45 50 35/35 40/35 45/45
Oil Charge, gallons ckt1/ckt2 1.8 1.8 1.7 2.2 1.8/1.8 1.8/1.8 1.7/1.7
Shipping Weight Aluminum Fin Coils, lbs 1454 1567 1799 2034 2942 2968 3196
Operating Weight Aluminum Fin Coils, lbs 1481 1597 1829 2077 2967 3001 3233
NOMINAL COMPRESSOR CAPACITY
Compressor 1 8 10 15 15 10 12 13
Compressor 2 8 10 13 15 10 12 13
Compressor 3 – – – – – – –
Compressor 4 – – – – 10 10 13
Compressor 5 – – – – 10 10 13
Compressor 6 – – – – – – –
CONDENSER
Total Face Area ft
2
34.7 34.7 43.5 43.5 87 87 116
Number of Rows Deep
Circuit 1 2 3 3 3 2 2 3
Circuit 2 – – – – 2 2 3
Fins per Inch 17 17 13 13 17 17 17
CONDENSER FANS, LOW SOUND
Number of Fans
Circuit 1 2 2 2 2 2 2 2
Circuit 2 – – – – 2 2 2
Fan Power hp/fan 0.3 0.3 1.2 1.2 1.2 1.2 1.2
Fan RPM 920 920 950 950 950 950 950
Total Chiller CFM 10833 10833 20000 20000 39500 39500 43333
EVAPORATOR
Water Volume Gallons 1.2 1.6 2.5 3.2 2.7 3.5 3.5
Maximum Water Side Pressure PSIG 300 300 300 300 300 300 300
Maximum Refrig Side Pressure PSIG 450 450 450 450 450 450 450
Minimum Chiller Water Flow GPM 10 10 10 10 40 40 60
Maximum Chiller Water Flow GPM 150 150 150 150 200 200 300
Water Connection Size Inches 2 2 2 2 3 3 3
