Quantech QTC2015T User Manual

QUANTECH
FORM QTC2-eg1 (515)
54
Electrical Notes
VOLTAGE CODE UNIT POWER MIN. MAX.
-17 200-3-60 180 220
-28 230-3-60 207 253
-40 380/415-3-60 342 440
-46 460-3-60 414 506
-58 575-3-60 517 633
UNIT VOLTAGE
UNIT
VOLTAGE
CONTROL
POWER
MCA
1
OVER CURRENT PROTECTION
2
NF DISC SW
MIN MAX
MODELS
WITHOUT
CONTROL
TRANSFORMER
- 115-1-60 15A 10A 15A 30 A / 240V
MODELS
WITH
CONTROL
TRANSFORMER
-17 200-1-60 15A 10A 15A 30 A / 240V
-28 230-1-60 15A 10A 15A 30 A / 240V
-40 380-1-60 15A 10A 15A 30 A / 480V
-46 460-1-60 15A 10A 15A 30 A / 480V
-58 575-1-60 15A 10A 15A 30 A / 600V
1. Minimum #14 AWG, 75°C, Copper Recommended
2. Minimum and Maximum Over Current Protection, Dual Element Fuse or Circuit Breaker
LEGEND
ACR LINE ACROSS THE LINE START
C.B. CIRCUIT BREAKER
D.E. DUAL ELEMENT FUSE
DISC SW DISCONNECT SWITCH
FACT MOUNT CB FACTORY MOUNTED CIRCUIT BREAKER
FLA FULL LOAD AMPS
HZ HERTZ
MAX MAXIMUM
MCA MINIMUM CIRCUIT AMPACITY
MIN MINIMUM
MIN NF MINIMUM NON FUSED
RLA RATED LOAD AMPS
S.P. WIRE SINGLE POINT WIRING
UNIT MTD SERV SW UNIT MOUNTED SERVICE (NON-FUSED DISCONNECT SWITCH)
LRA LOCKED ROTOR AMPS
