Electrical Data - 60Hz
QTC2015T - QTC2045T
WIRING WITHOUT PUMP
See Electrical Notes on page 54
QTC2 VOLT HZ
MIN
CKT.
AMPS
MCA
MIN
N/F
DISC
SW
MDSW
MIN
DUAL
ELEM
FUSE
MAX
DUAL
ELEM
FUSE
MAX CB
SYSTEM # 1 SYSTEM # 2
COMPR 1 COMPR 2 FAN COMPR 1 COMPR 2 FAN
RLA LRA RLA LRA QTY FLA LRA RLA LRA RLA LRA QTY FLA LRA
015T
200 60 101 150 125 125 42.2 250 42.2 250 2 2.6 5.0 – – – – – – –
230 60 94 100 110 125 39.0 250 39.0 250 2 2.6 5.0 – – – – – – –
380 60 54 60 60 70 22.5 155 22.5 155 2 1.6 3.0 – – – – – – –
460 60 45 60 50 60 18.6 114 18.6 114 2 1.3 2.5 – – – – – – –
575 60 36 60 40 50 14.9 100 14.9 100 2 1.0 2.0 – – – – – – –
020T
200 60 108 150 125 150 45.4 250 45.4 250 2 2.6 5.0 – – – – – – –
230 60 100 150 125 125 42.0 250 42.0 250 2 2.6 5.0 – – – – – – –
380 60 58 60 70 80 24.2 155 24.2 155 2 1.6 3.0 – – – – – – –
460 60 48 60 60 60 20.0 125 20.0 125 2 1.3 2.5 – – – – – – –
575 60 39 60 45 50 16.0 100 16.0 100 2 1.0 2.0 – – – – – – –
025T
200 60 136 150 175 175 51.3 300 55.8 425 2 7.6 44.0 - - - - - - -
230 60 136 150 150 175 51.3 300 55.8 425 2 7.4 19.1 - - - - - - -
380 60 81 100 90 110 26.9 139 36.0 239 2 4.5 23.1 - - - - - - -
460 60 65 100 80 90 23.1 150 26.9 187 2 4.0 19.0 - - - - - - -
575 60 55 60 70 70 19.9 109 23.7 148 2 2.9 15.3 - - - - - - -
030T
200 60 151 200 175 200 59.9 425 59.9 425 2 7.6 30.9 – – – – – – –
230 60 140 150 175 175 55.5 425 55.5 425 2 7.4 37.0 – – – – – – –
380 60 81 100 90 110 32.0 239 32.0 239 2 4.5 22.3
– – – – – – –
460 60 67 100 80 90 26.4 187 26.4 187 2 3.4 17.2 – – – – – – –
575 60 54 60 60
70 21.1 148 21.1 148 2 2.9 14.6 – – – – –
–
–
