Quantech QTC2015T - Page 51

FORM QTC2-eg1 (515)
QUANTECH
51
MODEL NUMBER
RATED CAPACITY
LBS (KG)
RATED DEFLECTION
IN (MM)
DURO (± 5)
RD3-BROWN-WR 250 (113) 0.5 (12) 40
RD3-BRICK RED-WR 525 (238) 0.5 (12) 50
RD3-LIME-WR 750 (340) 0.5 (12) 60
RD3-CHARCOAL-WR 1100 (499) 0.5 (12) 70
MODEL NUMBER
RATED CAPACITY
LBS (KG)
RATED DEFLECTION
IN (MM)
DURO (± 5)
RD4-BROWN-WR 1500 (680) 0.5 (12) 40
RD4-BRICK RED-WR 2250 (1021) 0.5 (12) 50
RD4-LIME-WR 3000 (1361) 0.5 (12) 60
RD4-CHARCOAL-WR 4000 (1814) 0.5 (12) 70
Isolator Details (Cont'd)
ELASTOMERIC ISOLATOR
