Quantech QTC2015T User Manual

FORM QTC2-eg1 (515)
QUANTECH
17
Physical Data and Nominal Ratings (Cont'd)
SI
QTC2 015T 020T 025T 030T 035T 040T 045T
LENGTH 2788.9 2788.9 3012.4 3012.4 3677.9 3677.9 3779.5
WIDTH 1135.4 1135.4 1135.4 1135.4 2301.2 2301.2 2301.2
HEIGHT 1170.9 1170.9 1270 1270 1214.1 1214.1 1590
NOMINAL KW 51 62.6 85.4 98.4 122.7 133.6 158.9
EER (AT AHRI) 10.6 10.3 10.8 11.1 10.7 10.8 11.1
IPLV 15.5 17.1 14.7 15.9 16.7 16.8 16.2
Number of Refrigerant Circuits 1 1 1 1 2 2 2
Refrigerant Charge, Opt, R-410A (kg) Circuit 1/Circuit 2 11.3 13.6 20.4 22.7 15.9/15.9 18.1/15.9 20.4/20.4
Oil Charge, gallons Circuit 1/Circuit 2 6.8 6.8 6.5 8.3 6.8/6.8 6.8/6.8 6.4/6.4
Shipping Weight Aluminum Fin Coils, kg. 659.5 710.8 816 922.6 1334.5 1346.3 1449.7
Operating Weight Aluminum Fin Coils, kg 671.8 724.4 829.6 942.1 1345.8 1361.2 1466.5
NOMINAL COMPRESSOR CAPACITY
Compressor 1 28.1 35.1 52.7 52.7 35.1 42.2 45.7
Compressor 2 28.1 35.1 45.7 52.7 35.1 42.2 45.7
Compressor 3 – – – – – – –
Compressor 4 – – – – 35.1 35.1 45.7
Compressor 5 – – – – 35.1 35.1 45.7
Compressor 6 – – – – – – –
CONDENSER
Total Face Area m
2
3.2 3.2 4 4 8.1 8.1 10.8
Number of Rows Deep
Circuit 1 2 3 3 3 2 2 3
Circuit 2 – – – – 2 2 3
Fins per Inch 17 17 13 13 17 17 17
CONDENSER FANS, LOW SOUND
Number of Fans
Circuit 1 2 2 2 2 2 2 2
Circuit 2 – – – – 2 2 2
Fan Power kW/fan 0.2 0.2 0.9 0.9 0.9 0.9 0.9
Fan RPM 920 920 950 950 950 950 950
Total Chiller l/s 5112.6 5112.6 9438.9 9438.9 18641.7 18641.7 20450.7
EVAPORATOR
Water Volume Liters 5.5 7.3 11.4 14.5 12.3 15.9 15.9
Maximum Water Side Pressure Barg 20.7 20.7 20.7 20.7 20.7 20.7 20.7
Maximum Refrig Side Pressure Barg 31 31 31 31 31 31 31
Minimum Chiller Water Flow l/s 0.6 0.6 0.6 0.6 2.5 2.5 3.8
Maximum Chiller Water Flow l/s 9.5 9.5 9.5 9.5 12.6 12.6 18.9
Water Connections Size Inches 2 2 2 2 3 3 3
