Quantel Ultra ICE 450 User Manual

Drawings | Contents | 67
|
Ultra
Version M 22-April-2012
|
Ultra
9.0 Laser Head with MVAT
Ultra 1064nm
RADIUS
3.3 [84]
BEND
13.2 [334]
NITROGEN PURGE
ACCESS (BOTH SIDES
ULTRA, 1064 WITH MVAT
OUTPUT
APERTURE
0
1.33 33.8
2.030 51.57
2.11 53.6
0 1.13 28.6 3.000 76.20 3.14 79.8 .125 3.18 2.875 73.03
.580 14.74
1.530 38.87
2-56 TAPPED
HOLES (4X)
(FROM BELOW - 3X)
6-32 TAPPED MOUNTING HOLE
0
.275 6.99
2.725 69.22
1.500 38.10
0
.370 9.40
6.265 159.13
10.18 258.4
.690 17.53
.6
15
1/8" [3.175mm]
ALIGNMENT PIN
SLIP-FIT HOLE AND SLOT
(FROM BELOW)
SHUTTER
