DAE/Veeam Memory Module Installation
Quantum DXi4700 Installation Guide 81
Figure 68: Removing the Cooling Shroud
1
1. Cooling shroud
8. Remove the cooling-fan assembly by lifting the release levers upwards (see Figure 69 on the next
page).
