DAE/Veeam Memory Module Installation
Quantum DXi4700 Installation Guide 82
Figure 69: Removing the Cooling-Fan Assembly
1
2
3
4
5
6
Item Description
1 Cooling-fan assembly
2 Cooling fan
3 Release lever (2)
4 Guide pin on the system board (2)
5 Cooling-fan connector (6)
6 Guide pin on the chassis (6)
9. Lift the cooling-fan assembly out of the Node.
Figure 70 on the next page illustrates the interior of the DXi4700 Node with the cover removed.
