Chapter 9: Configuration
Notifications
Quantum DXi4700 User’s Guide 286
Adding a Community
Add an SNMP community to include the DXi4700 in a group of devices that are monitored by a common
management station.
Note: If no communities are defined, the SNMP agent is not accessible.
To add a community:
1. Click Add.
The Add SNMP Community page displays (see Figure 179 below).
Figure 179: Add SNMP Community Page
2. In the Name box, enter a unique Name for the community (up to 20 characters).
Valid characters are letters, numbers, hyphens, and underscores.
3. Enter a valid IP Address and Network Mask pair.
A pair is valid if performing a logical bitwise AND operation on the IP address and the network mask
results in the IP address. See the table below for examples:
IP Address / Network Mask Result
10.40.166.87
255.255.255.255
Allows access only from 10.40.166.87
10.40.166.87
10.40.166.87
Allows access only from 10.40.166.87
10.40.166.87
10.40.166.0
Invalid because the logical bitwise operation (address AND mask) is
not equal to the address
