Quantum Q-Logic 3 Programming Guide

10
Programming Jack Commands
Jack Commands are where functions can be programmed
for either a short, double or long command for both the On/
Off Jack and Mode Jack.
1. Parameter Settings/Program Adjustments
2. Enhanced Display or SCIM
3. Jack Commands
 Click on the item under the jack to which you would
like to assign a function.
 Select from the drop down menu which function is
to be assigned.
Programming Jack Double Commands
Jack Double Command Time adjusts the time required to
provide a double command on the switch that is plugged into
the Enhanced Display.
1. Parameter Settings/Program Adjustments
2. Enhanced Display or SCIM
3. Switch Options/Timing
 Jack 1 Double Command Time: Can be adjusted
by moving the slide bar.
 Teach Double Command Time: Can be done
by clicking on the Start button and following the
directions provided for the end user to set their own
double command time.
Programming Jack Long Commands
Jack Long Command Time adjusts the time required to
provide a long command on the switch that is plugged into
the Enhanced Display
1. Parameter Settings/Program Adjustments
2. Enhanced Display or SCIM
3. Switch Options/Timing
 Jack 1 Long Command Time: Can be adjusted by
moving the slide bar.
 Teach Long Command Time: Can be done
by clicking on the Start button and following the
directions provided for the end user to set their own
double command time.
Programming Mode Jack E-Stop
Mode Jack E-Stop enables the switch plugged into the
mode jack to perform an emergency stop command.
1. Parameter Settings/Program Adjustments
2. Enhanced Display or SCIM
3. Switch Options/Timing
4. On/Off Jack E-Stop
 Off: E-Stop will not function.
 Decal Stop: Power chair will come to a gradual stop
using the programmed deceleration.
 Quick Stop: Power chair will come to an abrupt
stop.
Programming Mode Jack Switch Type
If the Mode Jack Switch Type is set to 1 Switch, then the
mode jack can only accept one single switch.
If the Mode Jack Switch Type is set to 2 Switch, then a
splitter must be installed. Quantum Rehab has available for
purchase a stereo to mono splitter. The two switches, both 1
and 2, can be plugged into the Mode Jack where even more
features can be programmed.
1. Parameter Settings/Program Adjustments
2. Enhanced Display or SCIM
3. Switch Options/Timing
 Mode Jack Switch Type (On/Off Jack Switch Type
can be programmed the same way)
Programming On/Off Jack E-Stop
On/Off Jack E-Stop enabled the switch plugged into the On/
Off jack to perform an emergency stop command.
1. Parameter Settings/Program Adjustments
2. Enhanced Display or SCIM
3. Switch Options/Timing
4. On/Off Jack E-Stop
 Off: E-Stop will not function.
 Decel Stop: Power chair will come to a gradual stop
using the programmed deceleration.
 Quick Stop: Power chair will come to an abrupt
stop.
HEAD ARRAY
