Chapter 3 Calibration
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging, LLC 3-25
APR Format Setting
The APR Format Setting key (shown below) permits the operator to configure
the APR Procedure Screens to display or not display the Film Speed and/or
CM (thickness) screen fields when the generator is operated in APR mode. To
change the APR Format setting, proceed as follows:
Figure 3-20. Choosing Language and Date Format Settings
Press the key next to the APR Format field to scroll through available APR
Format options:
• All Windows - APR Procedure Screens will display both Film Speed
and CM (thickness) screen fields
• No CM - APR Procedure Screens will not display the CM (thickness)
screen field
• No FS - APR Procedure Screens will not display the film speed
screen field
• No FS, No CM - APR Procedure Screens will not display the film
speed nor the CM (thickness) screen fields
PRESS THIS
KEY TO
SELECT APR
FORMAT
SETTING
