Quantum QG-5000

Chapter 1 Specifications
Revision W HF Series X-ray Generators - Service Manual
1-12 Quantum Medical Imaging
Table 1-2. HF Series Generators -
Electrical Wiring Requirements (380 - 480 VAC Single-Phase Input Units)
*NOTE: All installations must meet the requirements of local electrical codes.
The above values are recommended as typical (unless otherwise specified).
*
1.
Input Voltage: 380-480 (±10%) VAC 50/60 Hz (configured at time of installation)
. Ground wire size is 4 AWG.
7. Specifications are subject to change.
All wire must be copper.
2. Actual wire size depends on power quality and distance between mains power
and the generator.
3. All wiring and grounding must be in accordance with National
Electric Code (NFPA #70) or local electrical codes.
4. The disconnect switch must be located within reach of the operator.
5. .
6
GENERATOR
MODEL NO.
MAX. POWER
OUTPUT (kW)
NOMINAL LINE
VOLTAGE (VAC)
DISCONNECT
TO GENERATOR
15 FT. (5 M) MAX.
*SERVICE
RATING
*RECOMMENDED
DISTRIBUTION
TRANSFORMER
CAPACITY
MAX. INPUT LINE
RESISTANCE
(AT FULL-LOAD
RMS)
GENERATOR
CATALOG NO.
25
32
40
QG-25-5
QG-32-5
QG-40-5
QG-250-5
QG-320-5,
QG-3200-5,
QGV-32-5
QG-400-5,
QG-4000-5,
QGV-40-5
380
#6 AWG 60 AMPS
32 KVA
0.028 OHMS
415 #6 AWG 55 AMPS 32 KVA 0.028 OHMS
480 #6 AWG 40 AMPS 32 KVA 0.032 OHMS
380 #6 AWG 75 AMPS 40 KVA 0.024 OHMS
415 #6 AWG 70 AMPS 40 KVA 0.024 OHMS
480
#6 AWG 60 AMPS
40 KVA
0.028 OHMS
380 #4 AWG 100 AMPS 50 KVA 0.015 OHMS
415
#4 AWG 90 AMPS
50 KVA
0.020 OHMS
480
#6 AWG 70 AMPS
50 KVA
0.024 OHMS
