Chapter 2 Assembly & Installation
HF Series X-ray Generators - Service Manual Revision W
Quantum Medical Imaging 2-45
tions are compatible with the supplied dual voltage power adaptor). See
Figure 2-24b.
Figure 2-24a. OCP Interface Board - AY40-073S (Ethernet Connection)
Figure 2-24b. Ethernet Switch Box (Grounded)
GENERATOR
LOGIC BOARD
(AY40-006S)
ETHERNET
CABLE
CONNECTION
OCP INTERFACE
BOARD
(AY40-073S)
To Next Page
