Quantum QN-I-270 User Manual

13 | www.qntmnet.com
Router
 Select option Router and click “Proceed”.
 Configure WLAN (SSID) and Local subnet parameters and click “Proceed”.
Parameter
Value
WLAN
WLAN Name
Define a name for the network
SSID
Define visible wireless network name
Password
Configure passphrase for SSID
Local Subnet
IP Address
LAN IP address. This IP address can be used for
accessing this Access Point
Subnet Mask
LAN Subnet mask
Figure 12 Figure 13
Note: If you do not want to create WLAN (SSID)/LAN now, click the Skip option. It will
turn to Configuration Summary.
