Quantum QXS 12G Series Drive Rackmount Install Guide

Install the 12-Drive and 24-Drive Chassis Rails
QX and QXS 12- and 24-Drive Rackmount Install Guide 9
2. Repeat step 1 to attach the other bracket to the other side of the chassis.
Figure 5: Attaching bracket to a 12-drive enclosure
11
1. Screws (2 per bracket)
Figure 6: Attaching bracket to 24-depth enclosure (standard-depth)
1
1. Screws (2 per bracket)

Quantum QXS 12G Series Specifications

General

Brand	Quantum
Model	QXS 12G Series
Category	Storage
Language	English
