GL200 User Manual
2.3. LEDs Description
There are three LED in GL200, the description as following.
Light Event State
Searching network
Fast flash
Network has been registered Slow flash
GSM light
Power off Dark
GPS has fixed Solid
GPS is in fixing Fast flash
GPS is on and GPS data wrong Slow flash
GPS is off Dark
GPS light
If “LED On” is not selected, and the GPS LED
will not work after turn on 150 seconds.
Dark
Power on and normal Dark
Charger inserted and charging completed Solid
Charger inserted and charging Fast flash
Power key was pressed and prepare to power off Fast flash
Abnormal
Fast flash
Power low alert
Slow flash
Power light
Power off or turn off the power light by command
Dark
2.4. External Power Interface
2.4.1. External DC Charger Interface
The Pin2 on Mini-USB connector are used for charging and named as VCHG pin, It can be
connected to a 5V DC power supply to power GL200 and charge the internal battery.
