Page #9 background imageLoading...
Page #9 background image
GV75MG User Manual
4. Device Cable Color
Table 7. GV75MG Device Cable Color Definition
Definition Color Pin No. Cable
RXD Gray 1
TXD Violet 2
OUT1 Blue 3
OUT2 Green 4
IGN White 5
IN1 Yellow 6
GND Black 7
VIN Red 8
QSZTRACGV75MGUM0101 6
