Quectel EC21 Series User Manual

LTE Standard Module Series
EC21_Series_Hardware_Design
100
/ 118
DCS1800 2DL/3UL @ 26.05 dBm 283.0 mA
DCS1800 1DL/4UL @ 25.14 dBm 357.0 mA
PCS1900 4DL/1UL @ 29.39 dBm 159.7 mA
PCS1900 3DL/2UL @ 28.06 dBm 234.6 mA
PCS1900 2DL/3UL @ 26.01 dBm 289.0 mA
PCS1900 1DL/4UL @ 25.20 dBm 363.9 mA
EDGE data
transfer
(GNSS OFF)
GSM850 4DL/1UL PCL = 8 @ 26.86 dBm 169.9 mA
GSM850 3DL/2UL PCL = 8 @ 25.76 dBm 284.1 mA
GSM850 2DL/3UL PCL = 8 @ 23.68 dBm 387.2 mA
GSM850 1DL/4UL PCL = 8 @ 22.39 dBm 498.7 mA
EGSM900 4DL/1UL PCL = 8 @ 27.01 dBm 171.0 mA
EGSM900 3DL/2UL PCL = 8 @ 25.82 dBm 286.0 mA
EGSM900 2DL/3UL PCL = 8 @ 23.64 dBm 389.0 mA
EGSM900 1DL/4UL PCL = 8 @ 22.46 dBm 500.0 mA
DCS1800 4DL/1UL PCL = 2 @ 25.90 dBm 133.0 mA
DCS1800 3DL/2UL PCL = 2 @ 24.98 dBm 220.0 mA
DCS1800 2DL/3UL PCL = 2 @ 22.92 dBm 308.0 mA
DCS1800 1DL/4UL PCL = 2 @ 21.82 dBm 403.0 mA
PCS1900 4DL/1UL PCL = 2 @ 25.36 dBm 132.4 mA
PCS1900 3DL/2UL PCL = 2 @ 25.07 dBm 220.9 mA
PCS1900 2DL/3UL PCL = 2 @ 23.13 dBm 307.2 mA
PCS1900 1DL/4UL PCL = 2 @ 21.82 dBm 402.8 mA
WCDMA data
transfer
(GNSS OFF)
WCDMA B1 HSDPA @ 22.78 dBm 530.0 mA
WCDMA B1 HSUPA @ 22.12 dBm 542.0 mA
WCDMA B2 HSDPA @ 22.54 dBm 556.3 mA
