LTE Standard Module Series
EC21_Series_Hardware_Design
101
/ 118
WCDMA B2 HSUPA @ 22.17 dBm 542.4 mA
WCDMA B4 HSDPA @ 23.27 dBm 491.0 mA
WCDMA B4 HSUPA @ 23.19 dBm 504.0 mA
WCDMA B5 HSDPA @ 23.18 dBm 480.4 mA
WCDMA B5 HSUPA @ 22.90 dBm 490.0 mA
WCDMA B8 HSDPA @ 22.32 dBm 504.0 mA
WCDMA B8 HSUPA @ 22.26 dBm 528.0 mA
LTE data transfer
(GNSS OFF)
LTE-FDD B1 @ 23.48 dBm 690.0 mA
LTE-FDD B2 @ 22.85 dBm 696.7 mA
LTE-FDD B3 @ 23.45 dBm 655.0 mA
LTE-FDD B4 @ 23.16 dBm 603.0 mA
LTE-FDD B5 @ 23.61 dBm 558.0 mA
LTE-FDD B7 @ 23.40 dBm 704.0 mA
LTE-FDD B8 @ 23.57 dBm 663.0 mA
LTE-FDD B28A @ 23.49 dBm 763.0 mA
LTE-FDD B28B @ 23.65 dBm 780.0 mA
LTE-TDD B40 @ 23.66 dBm 340.3 mA
GSM voice call
GSM850 PCL = 5 @ 32.45 dBm 234.9 mA
EGSM900 PCL = 5 @ 32.81 dBm 249.0 mA
DCS1800 PCL = 0 @ 29.28 dBm 143.0 mA
PCS1900 PCL = 0 @ 29.47 dBm 154.5 mA
WCDMA voice call
WCDMA B1 @ 23.44 dBm 568.0 mA
WCDMA B2 @ 23.15 dBm 614.0 mA
WCDMA B4 @ 23.20 dBm 497.0 mA
WCDMA B5 @ 23.23 dBm 492.0 mA
