Quectel EC21 Series User Manual

LTE Standard Module Series
EC21_Series_Hardware_Design
73
/ 118
LTE-FDD B13 (10 MHz) -97.7 dBm -97.0 dBm -100.0 dBm -93.3 dBm
Table 31: EC21-AU Conducted RF Receiving Sensitivity
Frequency Bands
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
8
GSM850 -109.0 dBm - - -102.0 dBm
EGSM900 -109.0 dBm - - -102.0 dBm
DCS1800 -109.0 dBm - - -102.0 dBm
PCS1900 -109.0 dBm - - -102.0 dBm
WCDMA B1 -110.0 dBm - - -106.7 dBm
WCDMA B2 -110.0 dBm - - -104.7 dBm
WCDMA B5 -111.0 dBm - - -104.7 dBm
WCDMA B8 -111.0 dBm - - -103.7 dBm
LTE-FDD B1 (10 MHz) -97.2 dBm -97.5 dBm -100.2 dBm -96.3 dBm
LTE-FDD B2 (10 MHz) -98.2 dBm - - -94.3 dBm
LTE-FDD B3 (10 MHz) -98.7 dBm -98.6 dBm -102.2 dBm -93.3 dBm
LTE-FDD B4 (10 MHz) -97.7 dBm -97.4 dBm -100.2 dBm -96.3 dBm
LTE-FDD B5 (10 MHz) -98.0 dBm -98.2 dBm -101.0 dBm -94.3 dBm
LTE-FDD B7 (10 MHz) -97.7 dBm -97.7 dBm -101.2 dBm -94.3 dBm
LTE-FDD B8 (10 MHz) -99.2 dBm -98.2 dBm -102.2 dBm -93.3 dBm
LTE-FDD B28 (10 MHz) -98.6 dBm -98.7 dBm -102.0 dBm -94.8 dBm
LTE-TDD B40 (10 MHz) -97.2 dBm -98.4 dBm -101.2 dBm -96.3 dBm
