Quectel EC21 Series

LTE Standard Module Series
EC21_Series_Hardware_Design
74
/ 118
Table 32: EC21-EU Conducted RF Receiving Sensitivity
Frequency Bands
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
8
EGSM900 -109.0 dBm - - -102.0 dBm
DCS1800 -109.0 dBm - - -102.0 dBm
WCDMA B1 -110.5 dBm - - -106.7 dBm
WCDMA B8 -110.5 dBm - - -103.7 dBm
LTE-FDD B1 (10 MHz) -98.2 dBm -99 dBm -101.7 dBm -96.3 dBm
LTE-FDD B3 (10 MHz) -98.7 dBm -99.5 dBm -101.2 dBm -93.3 dBm
LTE-FDD B7 (10 MHz) -96.8 dBm -98.5 dBm -100.7 dBm -94.3 dBm
LTE-FDD B8 (10 MHz) -98.7 dBm -100 dBm -101.7 dBm -93.3 dBm
LTE-FDD B20 (10 MHz) -98.2 dBm -99.5 dBm -101.8 dBm -93.3 dBm
LTE-FDD B28A (10 MHz) -98.8 dBm -100 dBm -101.5 dBm -94.8 dBm
Table 33: EC21-AUT Conducted RF Receiving Sensitivity
Frequency Bands
Receiving Sensitivity (Typ.)
3GPP (SIMO)
Primary Diversity SIMO
8
WCDMA B1 -110.0 dBm - - -106.7 dBm
WCDMA B5 -110.5 dBm - - -104.7 dBm
LTE-FDD B1 (10 MHz)
-
98.5 dBm -98.0 dBm -101.0 dBm -96.3 dBm
LTE-FDD B3 (10 MHz) -98.0 dBm -97.0 dBm -100.0 dBm -93.3 dBm
LTE-FDD B5 (10 MHz) -98.0 dBm -99.0 dBm -102.5 dBm -94.3 dBm
LTE-FDD B7 (10 MHz) -97.0 dBm -97.0 dBm -98.5 dBm -94.3 dBm
LTE-FDD B28 (10 MHz) -97.0 dBm -99.0 dBm -102.0 dBm -94.8 dBm
